How Do I Install A Rainwater Diverter?

“I’m working on making my backyard farm more sustainable and I’d like to install a rainwater diverter to collect water from my roof for my garden. Could you provide detailed instructions on how to install a rainwater diverter including what tools and materials I would need? My problem is that every time it rains, a lot of water is wasted, and I have to rely on municipal water for my garden. I live in a suburb, and most homes here have sloped roofs and standard downspouts.” Thanks, Victoria, Portland, USA.

Hey Victoria! Installing a rainwater diverter is a fantastic idea for anyone looking to make their backyard farm more self-sustaining. It captures rainwater from your roof and redirects it into your chosen storage system, like a rain barrel, rather than letting it go to waste. Let’s get you started.

Understanding the Basics of Rainwater Diversion

Rainwater diverters are handy devices that connect to your downspout and channel rainwater into a barrel or tank. They’re designed to divert the first flush of water, which often contains debris and contaminants, allowing cleaner water to be stored. This system can significantly reduce your dependency on municipal water and help keep your garden green and healthy.

Benefits of Using a Rainwater Diverter

• Water Conservation: Saves water by capturing runoff from the roof.
• Cost Savings: Reduces your water bill by using collected rainwater for gardening.
• Environmental Impact: Less strain on municipal water supplies and reduced stormwater runoff.

Tools and Materials You’ll Need

• Rainwater diverter kit
• Rain barrel or tank
• Hacksaw
• Drill with bits
• Measuring tape
• Marker or pencil
• Rubber gloves
• Silicone sealant

Choosing the Right Rainwater Diverter Kit

When picking a rainwater diverter, make sure it’s compatible with your downspout size and type. Most diverters work with standard rectangular or round downspouts. Here are a couple of features to look for:

• Ease of Installation: Choose a kit that comes with clear instructions.
• Seasonal Adjustability: Some diverters allow you to switch them off during the winter.
• Debris Filtering: Opt for diverters with built-in filters to keep out leaves and other debris.

Steps to Install a Rainwater Diverter

Step 1: Choose the Installation Spot

Locate a downspout close to where you’ll place your rain barrel. Ensure the area is solid and level to support the weight of a full barrel. Victoria, it sounds like your situation matches this pretty well, considering the typical suburb design.

Step 2: Prepare Your Downspout

• Measure and Mark: Measure the height of your rain barrel and mark the downspout where you’ll attach the diverter. Typically, this is around 2-3 feet from the ground.
• Cut the Downspout: Using a hacksaw, cut through the downspout at your marked location. Make sure your cuts are straight and clean.

Step 3: Attach the Diverter

• Install the Adapter: If your diverter kit includes an adapter, place it into the cut downspout section securely.
• Attach the Diverter: Connect the diverter to the adapter or directly to the downspout as per your kit’s instructions. Make sure it is snug to avoid leaks.

Step 4: Connect to the Rain Barrel

Now it’s time to link your newly installed diverter to your rain barrel:

• Drill an Intake Hole: If your rain barrel doesn’t have a pre-drilled hole, use a drill to create one at the appropriate height.
• Insert the Hose: Attach the hose from the diverter to the intake hole. Use silicone sealant to ensure the connection is watertight.

Step 5: Secure and Test the System

• Secure All Connections: Double-check all connections, ensuring the diverter and hose are tightly secured to prevent leaks.
• Test It Out: Run water through your roof system or wait for the next rain to ensure water is being diverted correctly into your barrel.

Maintaining Your Rainwater Diverter

Now that you have your system set up, let’s talk about keeping it in good working condition:

• Regular Inspections: Check the diverter and downspout connections for any signs of wear or damage. These regular checks, ideally monthly, can save you a lot of trouble in the long run.
• Clean Filters and Screens: If your diverter has filters, clean them frequently to ensure debris does not block the water flow. Clean filters can significantly enhance the efficiency of water collection.
• Winter Precautions: Disconnect and store the diverter hose during the winter to prevent freezing and cracking. Retract the diverter to direct water away from the rain barrel during these months.

Typical Issues and Troubleshooting

It’s helpful to be aware of some common problems and their solutions:

• Leakage: If you notice leaks around the diverter, recheck the connections and apply additional sealant if necessary.
• Poor Water Flow: Ensure there are no blockages in the diverter or downspout, and the hose is correctly positioned.
• Overflows: If your rain barrel overflows, consider adding an overflow pipe to direct excess water away safely.

Additional Tips and Tricks

Maximizing Efficiency

To make the most out of your rainwater collection system, consider these additional tips:

• Multiple Barrels: Connect several barrels together to store more water. Adding more barrels can be particularly useful in areas with high seasonal rainfall.
• Elevate Your Barrel: Place your rain barrel on a sturdy platform to use gravity to your advantage when you need to use the collected water.
• Reuse Collected Water: Use harvested rainwater for non-potable needs like irrigating plants, washing vehicles, or cleaning tools. This not only helps in water conservation but also provides your plants with chemical-free nutrient-rich water.

Legal and Safety Considerations

There are a few important things to check before you start collecting rainwater:

• Local Regulations: Check with local municipal codes to ensure rainwater harvesting is permitted in your area. Certain regions have specific regulations and permits needed for rainwater collection.
• Proper Sealing: Ensure your storage container is properly sealed to prevent mosquitoes and other pests from breeding in the standing water.
• Safety Precautions: Water collected should not be used for drinking unless properly treated. It’s best to use it for irrigation and other non-potable purposes.

FAQs About Rainwater Diverter Installation

Here is a quick FAQ to address some common questions people have about installing rainwater diverters:

Can I install a rainwater diverter myself, or do I need professional help?

Installing a rainwater diverter is a relatively straightforward DIY project that most people can handle with basic tools and some patience. The instructions provided in the kits are generally easy to follow.

Where should I place my rain barrel?

Your rain barrel should be placed on level ground, preferably close to your downspout. Elevating the barrel can help in water pressure when you use it for gardening.

How often should I clean my rainwater diverter?

It’s best to inspect and clean the diverter filters about once a month. Regular maintenance will ensure the system operates efficiently.

What if there’s no rain for a long period?

If there’s a drought or extended period without rain, you can still use municipal water temporarily to fill your rain barrels to keep your garden hydrated. However, the primary goal is to maximize the use of natural rainfall.

Is it safe to use rainwater for all plants?

Absolutely. Rainwater is free from chemicals and often has beneficial nutrients that tap water lacks, making it excellent for plant irrigation.

Final Thoughts…

Victoria, thanks for sending in your question. Setting up a rainwater diverter is an excellent step towards achieving sustainability in your backyard farm. Following these detailed steps will ensure you install it correctly and make the most of your collected rainwater. It’s simple, cost-effective, and incredibly beneficial for both your garden and the environment. Happy gardening!
